1.  Threading mechanism – to facilitate the metal bands to penetrate the oiling equipment.
2.  Photoelectric sensing system– to sense the blade strips and automatically control the oiling switch.
3.  Nozzles-atomizer and charging system– to produce and attach the charged oil mist to the metal surface
      in the electrostatic field.
4.  Oiling adjusting system– to adjust the oil volume according to the set oiling width.
5.  High voltage power supply– to charge oil mist and generate electrostatic adsorption effects.
6.  Oil supply system– including oil tank, filter and heater.
7.  Precision metering pump– used for metering oil supply amount under different speed, oiling width
      and oil volume requirements.

      •  Power supply： 220VDC/50Hz/1PH
      •  High voltage： 50KVDC@5mA
      •  Coating range： 100-500 mg/m² per side
      •  Coating width：13mm-80mm
      •  Min speed： 10 MPM
      •  Max power consumption： 5Kw
